Aviosys IP POWER 9850GE
IP Power 9850GE is a new generation of the Power Distribution Unit (PDU) & Remote Power Control (RPC) system.
With embedded web server and HTTPS protection , 9850XX supports higher grade security as working on Internet. User can control power easily and more safely through the web browser in Windows , Android or iOS system , like Internet Explorer (IE) , Google Chrome , Safari web browser or control through APP in Android or in iOS system .
With 4 buttons on device top, it allows user to direct control manually to each port ON/OFF with fingertip without web browser / APP , also allows remote control power on/off up to 4 separate devices via network .
As support SSL & SNMP, user can use public email like Gmail, Hotmail, Yahoo, to get the email as the ON/OFF status changed . User can also control by e-mail without doing port forwarding / port mapping and search the other IP Device in webpage directly and quick .
9850XX supports Auto Ping , Time Scheduler which is more suitable for factory / commercial / office / home automation . User can get the device status in LOG information or in remote IP address which sent to get LOG message from 9850 ( SYSLOG ) . .
For system integrator, there are several popular developing tolls like HTTP/CGI command , Telnet , SNMP , Modbus TCP/IP & BACnet TCP/IP .
The various applications of the 9850XX includes:
Power Management, Server Management, Internet Controllable Timer, System Integration, Remote Power Control in Remote locations, etc.
Features :
- 4 port Remote power controller for power On, Off and Reboot.
- Web Server built-in design, directly control by web browser in Windows , Android or iOS system like Internet Explore (IE) , Google Chrome and so on.
- 4 Buttons Control : Direct manual hardware control each outlet without working on Web browser
- Support HTTPS , SSL , TCP/ IP , DHCP, DDNS , SMTP , Telnet , SNMP , Modbus/TCP and BACnet/IP
Power Surge protection & FUSE embedded in. - SYSLOG: Support Log function & send to assign IP address
- Time Schedule: Pre-set a suitable time to turn power on/off automatically
- Auto Ping for network control & segment management automatically
- High grade components for long stability and performance
- Back Up for quick setup for multiple devices like Time Schedule, Network Setting.
- Support public e-mail SMTP from gmail, yahoo, hotmail, etc. E-mail Control & Advice : Receive e-mail with IPs device boot up. - POP3 Control–Control each outlet ON/OFF via E-mail. No need for port forwarding.
- Free software developed by Aviosys : SDK Available : HTTP Command - Windows software "IP Power Center" to control Multiple Aviosys IP Power devices in one software package, CNT software (Cross Network Technology), allows user eliminate set up work on any router without port forwarding , simply plug & play, support MQTT protocol.
Specifications :
- Power input : 15A/90-120VAC, 10A/210-240VAC, 50-60Hz
- Maximum loading of each output: 10Amp
- Maximum total loading 9850 unit : 10Amp
- Fuse protection: 10Amp
- Dimensions: 200 x 140 x 50 mm
- Weight: 990 gram
- Metal enclosure, deep gray color
- Operation Temperature : -10 °C to +60 °C
Minimum System Requirements (not included)
- Network
- Web Browser
- Internet Connection
- Ethernet Cable
- Power Cord
Package Contents
- 9850GE Unit
- Installation CD : include Manual with SDK and IP Search Software
