The T120 is a 2 wire transmitter for PT100 and Ni100 type probes, loop powered. Configuration software for easy configure the T120 parametres (start / full scale, rejection, RTD type, cable resistance, over-range etc.). The T120 is easy to wire using Push Wire Clamp Stype Connections and with a max resolution of 16bits and an accuracy of 0.1% it will display highly precise measurements.
Note: USB cable with software not included, see related products
• Pt100
Standard: EN 60751/A2 (ITS-90)
Measurement range: -200..+650°C
Minimum span: 20°C
Connection: 2,3,4 wires
• Ni100
Measurement range: -60..+650°C
Minimum span: 20°C
Connection: 2,3,4 wires
